PH01N: Horizontal pneumatic clamp

It is positioned on the bases of the different machines, with the possibility of 360º rotation. Ideal for different works on medium and small size profiles. When pressing horizontally, it leaves the upper side free for the design of fretwork, borders, drawings, etc. A very interesting option for its operation is to place a T, and use the air from the pneumatic pistons of the machine.

  • Compatible with all Vacuum CNC bases.
  • Variable height depending on the customer's needs.
  • Travel up to 150 mm.
  • Aperture distance of 100 mm.
  • Gripping force of 500 N (~50 Kg) at 8 bar pressure.
  • Pneumatic elbows for 6 mm hose.
